1. Controller output support USITT DMX512/1990 standard universal protocol and extended DMX protocol.

2. The controller signal output ADRI/PO terminal automatically programing through 512DMX channel, supporting the DMX512AP-N/NB, UCS512, MY7221, WS2821 and other driving chips.

3. The MR-318DW controller addressing signal output is compatible with the differential output signal, which improves the transmission distance and effective addressing.

4. The system supports automatic, timed, holiday preset effect playback;

5. Accurate gamma correction algorithm which is in line with human's visual light-sensing characteristics, creates more color and make animations perfect.

6. Maximum support for 120 frame change frequency to ensure high-definition display and 3D display.

7. The controller with buttons and external remote controller can realize the selection of program clips, overall brightness adjustment, white balance adjustment, playback speed adjustment, etc.

8. LCD display module shows controller parameters and status timely.

9. 32-65536 class grayscaness control, can realistically restore image color and details.

10. Support four-colors equipment, energy saving and environmental friendly.

11. SD card storage, the controller can support up to 32G and 99 program files.

12. Support remote online download and update of offline programs.

13. Built-in animation test program to enable on-site debugging.

1. 1.Four-color design: energy-saving and environmental friendly; 2. 2.Synchronous and asynchronous integrated control: online priority, no online signal automatically switches offline effects, to achieve video source backup. 3. 3.Large-scale independent developed video editing, playback and wiring design software: more adaptable, more language support, more open, suitable for variety of special-shaped screen, multi-screen, building screen, pixel light screen and other complex applications both at home and abroad. 4. 4.Support for current 32-bit, 64-bit operating systems: windows 2000, windows XP, windows 7, windows 8, etc. 5. 5.Support drive chips such as DMX512AP-N, DMX512AP-NB, UCS512, MY7221, WS2821, SM512-12, etc.

Rated voltage	AC 100V~240V
Rated power	15w
Lenth	283mm
Width	134mm
Hight	45mm
Hole spacing	268mm;68mm
Standard Accessories	The remote × 1/SD card × 1/AC power cord ×1
