Control:

DMX or ON/OFF

Channel:

1/4  1/2  1

Appearance:

Weight:8.5/4.5/3KG，Materials：Extruded aluminum+Die-cast aluminumend cap+Ultra-white transparent tempered glass，Color：RAL7012

Temperature Range:

-35℃ to 50℃（Starting）,-40°C to 50°C (Working),-40°C to 70°C (Storage)

Surface Temperature:（@50℃）

≤65

Protection Grade:

IP66

IK06

Windward Area（max m²）:

0.133

Environmental Certification:

ROHS

Certification

CQC

Cable:

3 core round-wire cable exposed 30cm, 3x1.0mm2（On-Off）

3 core round-wire cable exposed 30cm, 3x1.0mm2+4 core round-wire cable exposed 30cm, 4x0.4mm2 withIP66&IP67cable glands（DMX）
